Rekeying Pins - Manufacturer Depths

Click Here ->  Bottom Pins    Top/Master Pins    Standard Cylinder Springs

Each pack/bag contains approx. 144 pcs.

Kwikset Lock Pin Depths  - .003 Increment Depth Bottom Master Driver 1 .171 .024 180 2 .195 .045 .180 3 .219 .069 .180 4 .240 .093 .180 5 .264 .114 .180 6 .288 .138 .180	Schlage Lock Pin Depths  - .003 Increment Depth Bottom Master Driver 0 .165   .237 1 .180   .237 2 .195 .030 .237 3 .210 .045 .237 4 .225 .060 .200 5 .240 .075 .200 6 .255 .090 .200 7 .270 .105 .165 8 .285 .120 .165 9 .300 .135 .165	Weiser Lock Pin Depths  - .003 Increment Depth Bottom Master Driver 0 .168   .185 1 .186   .185 2 .204 .036 .185 3 .222 .054 .185 4 .240 .072 .185 5 .258 .090 .185 6 .276 .108 .185 7 .294 .126 .185 8 .312 .145 .185 9 .330 .160 .185
Corbin/Russwin Pin Depths .003 Increment Series 70 - Small Plug Depth Bottom Master Driver 1 .162 .027 .170 2 .189 .057 .170 3 .216 .084 .170 4 .246 .111 .170 5 .273 .141 .170 6 .300   .170	Corbin/Russwin Pin Depths .003 Increment Series 70 - Large Plug Depth Bottom Master Driver 1 .204 .027 .170 2 .231 .057 .170 3 .258 .084 .170 4 .288 .111 .170 5 .315 .141 .170 6 .345   .170
